Harrington NER010SD-20 H4 Electric NER Chain Hoist, 2,000 lb. Load Capacity, 230V, 20 ft. Hoist Lift, Lift Speed 28/4.5 fpm, 2 Speed

Harrington
Electric Chain Hoist
  • Availability: 1 In Stock
  • SKU: NER010SD-20
19,884 13,919
(vat inclusive)
Save 30%
DescriptionSpecificationReviews

Features

  • Electromagnetic brake Grade 80 nickel-plated steel chain Meet ASME B30.16
  • Designed to handle heavy- and severe-duty applications.
  • The variable-speed duty cycle is 30/10 min. with under-the-cover variable frequency drive with 2-step infinitely variable control and speed ratio of 6:1, adjustable up to 12:1.
  • Include smart brake technology.
  • H4 Rated Die-cast aluminum Friction clutch Oil bath lubrication Include chain containerchain hoist
Manual Chain Hoist
-Electric Chain Hoist
-Chain Hoist
Electric Hoist Item
Chain Hoist
Load Capacity
2,000 lb
Hoist Lift
20 ft
Classification
H4
Number of Speeds
2
Lift Speed
28/4.5 fpm
Motor HP
2.4 hp
Voltage
230
Phase
3
Min. Between Hooks
16 15/16 in
Amps @ Low Volts
9.1 A
Housing Depth
8 5/16 in
Housing Length
24 1/2 in
Housing Width
9 11/16 in
Reeving
1
Brake
DC Current
Clutch
Friction
Control
110V Push Button Control Pendant
Control Cord
16 ft
Color
Yellow
Finish
Electrostatic Enamel
Hz
60
Lubrication
Oil Bath
Thermal Protection
Yes
Standards
ASME B30.16, ASME HST-1M, NFPA 70, RoHS, UL1340
Includes
Chain Container, Quick Disconnect Plugs On Pendant and Power Cord
Hoist Mount
Hook Mounted - No Trolley
Weight
58.05
Khusheim Code
BD-14H724
Khusheim ID
980756
