Dayton 4Z518 AC Gearmotor 115/230 Nameplate RPM 15 RPM Max. Torque 202.0 in-lb Enclosure TEFC

Dayton
Gearmotor
  • Availability: 2 In Stock
  • SKU: 4Z518
1,576 1,103
(vat inclusive)
Save 30%
Tabby Installment Plan Split in 4 payments of 276 monthly without fees
DescriptionSpecificationReviews
Dayton® 115/230VAC PSC TEFC Parallel Shaft Gearmotor delivers up to 385 in.-lb. of torque and keeps your operations running smoothly. - Includes heavy-duty needle roller and thrust ball bearings on the case and ball bearings on the totally enclosed fan-cooled motor. - With permanent heavy gear oil lubrication. Capacitor is included. - Requires 1 disc adaptable Motor Brake No. 5X400, sold separately.
Electrical Supplies
Gearmotor Type
AC Gearmotor
Gearmotor Voltage
115/230V AC
Gearmotor Phase
1
Max. Torque
202.0 in-lb
Gearmotor Shaft Type
Single
Gearmotor Shaft Orientation
Parallel
Gearmotor Rotation
CW/CCW
Nameplate RPM
15 RPM
Gearmotor Enclosure
Totally Enclosed Fan-Cooled
Gearmotor Mounting Position
All Angle
Gearmotor Brake Type
None
Length Less Shaft
8 3/4 in
Hz
60/50 Hz
Overhung Load
175 lb
Input HP
1/15 hp
Gear Ratio
107
1
Full Load Amps
1.2/0.63
Max. Ambient Temp.
40 Degrees C
Motor Type
PSC
Capacitor Required
Included
Shaft Dia. (Dimension U)
5/8 in
Shaft Length (Dimension V)
1.5 in_x000D_
Number of Brake Discs Required
1
Bearings
Heavy Duty Needle Roller and Thrust Balls on Case, Ball on Motor
Lubrication
Permanent Heavy Duty Gear Oil
Housing
Die Cast Aluminum
Gear Case Material
Die Cast Aluminum
Gears
Hardened Steel, 1st Stage Helical, Subsequent Stages Spur, AGMA Class 9
Gear Material
Hardened Steel
Gear Type
Helical First Stage/Subsequent Stages Spur/AGMA Class 9
Seals
Lip Type on Input and Output Shaft
Standards
UL Recognized, C-UL Recognized, CE Certified
Weight
5.7
Khusheim Code
BD-4Z518
Khusheim ID
1808335
